HLG Greenhouse Pro HE is a commercial Indoor Horticulture LED grow light designed for greenhouse facilities, that features our integrated reflectors shown to improve the photon delivery to the canopy. This lamp has Full Spectrum White and Deep Red LED’s, with an efficacy of 3.4 µmol/joule.
Top Features
- Deep Red boosted with Plant-centric full spectrum
- High efficacy of 3.4 µmol/joule
- Slim Linear Design to minimize shadowing on plants
- Integrated reflectors maximizes photon deliver to the canopy
- Easy Installation
- Replaces HPS 1:1
- Controller Compatible
- Auto sensing power supply works on both 120VAC, 240VAC, and 277VAC
- 5 Year Warranty
Specifications of the HLG Greenhouse Pro HE
| Power | 0-630 Watts |
|---|---|
| Voltage Range | 120-277 VAC 50-60Hz, 277-500VAC |
| LED | Full Spectrum White & Deep Red |
| Flowering Footprint | 5' x 5' at 16"-24" |
| Veg Footprint | 6' x 6' at 30"-36” |
| System PPF Efficacy | 3.4 μmol/joule |
|---|---|
| Total output | 2100+ PPF |
| Dimensions | 59" x 6.75" x 4.75" |
| Product Weight | 14.6 lbs |
| Certifications | UL 8800, CSA, DLC |
| Brand | Horticulture Lighting Group |
|---|---|
| SKU | HLG-GREENHOUSE-PRO-HE-RJ-MAN |
| Weight (lb.) | 0.0000 |
| Prop 65 | No |
| Length (in.) | No |
| Width (in.) | No |
| Height (in.) | No |
| Warranty (*Spec-Box) | No |
| Lead Time | Built to order: Ships in 1 week |
| Hazmat? | No |
| UPC | No |
| Case/Pack/Pallet Amount | No |
| Lighting Type | LED |
| LED Light Spectrum | Full Spectrum |
| LED Fixture Type (New) | Panel |
| LED Fixture Type (Old - DNU) | No |
| LED Features | Manual Dimming Knob, Dimmable *with Controller |
| Est. Electricity Cost /mo (*Spec-Box) | $27.21 |
| Exact Watts (*Spec-Box) | 630 Watts |
| HID Equivalent | No |
| Suggested Hanging Height | 30"-36” Veg; 16"-24" Flower |
| LED Diode Type | No |
| LED Driver Type | No |
| PAR Efficiency | 3.4 μmol/J |
| Total PPF Output | 2100 μmol/s |
| Power Factor | No |
| Daisy Chain | No |
| Voltage (*Spec-Box) | 120/277 Volts |
| Amps | No |
| Frequency | No |
| Power Cord(s) Included | Yes |
| Power Cord Length | No |
| Coverage Area (*Spec-Box) | Veg: 6' x 6'; Flower: 5' x 5' |
| Grow Light Certifications | DLC Listed, ETL Listed, UL Listed, CSA Listed |
| ETL Listed | Yes |
| UL Listed | Yes |
| Dimming Option | RJ Ports & Manual Knob |
| Maintenance Information | No |
